Petroleum & Oilfield Hose

Ideal for the recovery of waste crude oil, diesel fuel, and saltwater, these hoses are used to clean up tank bottoms and oil spills. Made of an NBR and PVC tube with a PVC clockwise helix, our oilfield cleanup hoses offer the following benefits:

• Oil- and gas-resistant tube
• Flexibility and easy handling
• Full vacuum for all sizes
• Cold-weather resistance

Series 3085 Product Specifications

Used for the delivery of gasoline, diesel fuel, kerosene, and other fuels with aromatic content up to 40%, NBR (nitrile rubber)/PVC (polyvinyl chloride) drop hoses feature a single braid of high-tensile polyester yarn reinforcement. These hoses are able to withstand harsh environments involving gasoline and offer the following key features:

• High transfer pressures
• SΩ ground wire embedded into hose wall to prevent static electricity buildup
• “Go-Glide” external clockwise PVC helix for easy dragging

Series 3058 Product Specifications

These hoses are designed for the removal of vapors from gasoline and alternative fuels when being transferred from terminal storage operations to tanker truckers and tanker trucks to underground storage.

As with the polyurethane drop hoses discussed above, these models offer -40 ºF cold-weather resistance, sub-zero flexibility, “Go-Glide” external clockwise PVC helix for easy dragging, and SΩ ground wire embedded into the hose wall to prevent static electricity buildup. These models also ensure a clear visual flow.

Series 3040 Product Specifications

Series 3045 Product Specifications

Used for the transfer of petroleum products — including gasoline under pressure and gravity flow, as well tank farm applications at oil/gas drilling sites — these hoses feature a red corrugated cover and smooth, nitrile tube. Benefits include:

• Corrugated cover for enhanced flexibility
• Lightweight design and easy handling
• Weather- and abrasion-resistant cover

Series 4421 Product Specifications

Low-temperature petroleum suction hoses enable the efficient transfer of petroleum products, including gasoline under pressure or gravity flow. Featuring a blue CR APRM Class B corrugated cover, these hoses offer:

• Oil-, weather-, and abrasion-resistant cover
• High flexibility, even in extremely cold temperatures
• Full vacuum for all sizes
• Compounded design
  • Allows for resistance to temperatures as low as -65 °F

Series 4410 Product Specifications

Ideal for applications where full suction is required, these hoses are frequently used in crude oil, saltwater and freshwater, tank bottom, and diesel fuel handling.

With a black CR ARPM Class B cover and a smooth, black nitrile tube, these models provide the same benefits as our oil return hoses — a weather- and abrasion-resistant cover, fall vacuum for all sizes, and a highly oil-resistant Class A tube, which can handle petroleum products with aromatic content up to 50%.

Series 4418 Product Specifications

Series 4419 Product Specifications

Series 4436 Product Specifications

Used for connection to frack tanks, these 400 PSI hoses are designed for the discharge or conveyance of water and oil slurry mixtures. The tube is made of nitrile, while the cover is an EPDM (ethylene propylene diene monomer — M-class — rubber)/SBR (styrene-butadiene rubber) blend. These hoses offer the following benefits:

• HD construction to allow for applications up to 400 PSI
• Weather- and abrasion-resistant cover
• Oil-resistant Class C tube
  • Can handle gasoline and other petroleum products with aromatic content up to 50%

Series 4348 Product Specifications

Designed for the delivery of biofuels, gasoline, kerosene, and fuel oil, Jason’s polyurethane drop hoses also feature a single braid of high-tensile polyester yarn reinforcement. Ideal for low-temperature applications, these hoses provide the following benefits:

• High transfer pressures
• Clear visual flow
• -40 ºF cold-weather resistance
• Sub-zero flexibility
• “Go-Glide” external clockwise PVC helix for easy dragging
• SΩ ground wire embedded into hose wall to prevent static electricity buildup
• Vacuum of up to 29 inches of Hg

Series 3058 Product Specifications

For the suction and discharge (S&D) of petroleum-based products in truck and car operations — including gasoline under pressure and gravity flow — Jason’s nitrile petroleum suction hoses offer unmatched flexibility and reliability. Main features are listed below.

• Dual wire helix for increased flexibility
• Weather and ozone resistance
• Highly oil-resistant nitrile tube
  • Allows hose to handle petroleum products with aromatic content up to 50%

Series 4414 Product Specifications

Series 4424 Product Specifications

Designed for the S&D of biodiesel and ethanol blended fuels, these models are constructed of an ultra-high-molecular-weight polyethylene (UHMWPE) and a smooth, black CR (chloroprene rubber) cover. Features include:

• Optimal resistance to biofuels
• Weather- and abrasion-resistant cover
• Heat and ozone resistance
• Dual conductive copper wires for easy hose grounding
• Full vacuum for all sizes

Series 4423 Product Specifications

For the oil return lines of hydraulic systems in industrial and agricultural systems, Jason provides several ideal hose models. Main features are listed below.

• Weather- and abrasion-resistant cover
• Full vacuum for all sizes
• Highly oil-resistant Class A tube
  • Can handle petroleum products with aromatic content up to 50%

Series 4415 Product Specifications

To successfully convey hot tar and asphalt, hoses must be specially designed for ultimate strength, durability, and longevity. Jason offers hoses built specifically for hot tar and asphalt applications, featuring a smooth, black special-elastomer-compound tube and two- or four-ply high-tensile cord reinforcement with a steel wire helix. Other key features are listed below.

• Weather- and abrasion-resistant cover
• Anti-static and oil- and heat-resistant cover
• Abrasion- and heat-resistant (up to 356 ºF) special tube compound
• Full vacuum for all sizes

Series 4429 Product Specifications
